GRENTON DIGITAL IN 6+3, DIN, TF-Bus

Technical Information

• DC power supply: 24 V
• maximum power consumption: 0.15 W
• maximum device current(@24V): 6 mA
• maximum diameter of the connection wire for 230 Vac inputs: 2,5 mm²
• maximum diameter of the connection wire for potential-free inputs: 1,5 mm²
• maximum allowable voltage between an SW(x) input and "N" connector: 277 Vac
• maximum allowable voltage between any SW(x) inputs: 400 Vac
• weight: 100 g
• size (DIN): 4
• dimensions (h/w/d): 58/71/90 mm
• operational temperature range: 0 – 45 °C
