GRENTON CLU Z-Wave, DIN, Eth, TF-Bus
(0
reviews)
Sold by:
Inhouse product
Inhouse product
Price:
$407.00
/pc
Share:
Top Selling Products
The Common Logic Unit (CLU) module is the central unit of the Grenton hybrid (wired - wireless) system. It handles device logics and stores configurations (e.g. button configuration, light scenes, logic, scenarios). CLU communicates with the other extension modules included in the Smart Home via wire bus (Grenton TF-Bus) and by Z-wave radio if necessary. In larger and more advanced systems it is also possible to build a grid of CLUs by connecticg them through an Ethernet interface.
Properties
- stores Smart Home System configurations
- is responsible for all computing tasks
- stores user data locally (privacy)
- enables connecting the system to the Internet (remote management of a Smart Home)
- communicates with the other elements of the Grenton system over the wire or wireless interfaces
- enables connecting up to 48 modules (or 400 objects) on the system bus - TF-Bus
- communicates with subsequent CLU modules for building larger systems (scalability)
- equipped with Z-Wave radio interface (e.g. for connecting blinds and FAKRO roof windows)
- an Ethernet port for connecting to the Internet and local network
Technical Information
- DC power supply: 24 V
- maximum power consumption: 2.4 W
- maximum device current(@24V): 100 mA
- maximum wire cross section: 2.5 mm²
- maximal radio power: 1 mW
- weight: 145 g
- size (DIN): 4
- dimensions (h/w/d): 58/71/90 mm
- operational temperature range: 0 – 45 °C
