7" touchscreen keypad (INT-TSH2-W)

The INT-TSH2 keypad is dedicated for operation and programming of the INTEGRA, INTEGRA Plus and VERSA families of control panels. It is an ideal solution for users seeking easy daily operation of the alarm system and building automation elements, including the KNX system. The combination of large size and universal design makes the device perfectly suited to both modern and traditional interiors.

Features:

• 7" capacitive glass touchscreen with swipe gestures support
• 1024x600 screen resolution, 16.7 million colours (true colour)
• multi-level user customisable graphic interface
• up to 24 user screens

• customisable and adaptable interface screens
• more than 20 preset graphic themes
• custom themes support
• widgets for keypad operation, control of the alarm system and automation devices connected to the control panel
• system control via MACRO functions, which activate an entire chain of different commands (including building automation commands)
• quick activation of PANIC, FIRE, AND MEDICAL alarms
• integration with the INTEGRA (INTEGRA Firmware 1.20 or higher) and VERSA (VERSA Firmware 1.10 or higher) control panels
• screensaver with options to display clock, date, system component statuses (zones, doors, exits), and temperatures (INTEGRA and INTEGRA Plus only)
• option to display a slideshow (photo frame function)
• current system status notifications displayed on the taskbar
• 2 programmable hardwired zones (INTEGRA and INTEGRA Plus only)
• support for NO and NC type detectors, as well as roller shutter and vibration detectors;
• support for EOL, 2EOL and 3EOL configuration (3EOL in with the INTEGRA Plus only);
• programming of end-of-line resistor values
• built-in speaker for acoustic signalling
• adjustment of acoustic signalling volume
• adjustable screen brightness with day/night mode
• built-in microSD memory card slot (for storing photo frame pictures, additional screen wallpapers and custom sounds for audible signals of zone violations - chimes)
• tamper contact responding to the enclosure opening or detaching from the wall
• available in white (INT-TSH2-W) and black (INT-TSH2-B) enclosure
