HDMI Splitter MAX (1x2)

The 1x2 Splitter MAX is an Ultra HD PremiumTM 1x2 HDMI 2.0 splitter with maximum bandwidth capabilities, the ultimate splitter option for cinema purists, it supports the full HDMI 2.0 (a/b) 18Gbps max data rate, capable of carrying the most premium UHD/4K 60 4:4:4 content, with all HDR formats (10 & 12-bit), Dolby Vision®, HDR10+ and HLG.

Specification

Form factor Lightweight slender aluminium enclosure

Inputs x outputs 1 HDMI / 2 HDMI

Transmission tech. Native HDMI

Video bandwidth 594MHz

ESD protection ± 8kV (air-gap discharge) ± 4kV (contact discharge)

Device / Package weight 165g

Dimensions (W/D/H) 100 / 56 / 16mm

Power Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified)

Operating temperature 0°C ~ 40°C / 32°F ~ 104°F

Storage temperature -20°C ~ 60°C / -4°F ~ 140°F

Relative humidity 20~90 % RH (non-condensing)

Power consumption 2 W
